The LZZBJ9-12/150b/2 type current transformer is engineered to deliver precise current measurement and protection in medium voltage electrical systems. This high-quality current transformer ensures accurate performance and reliability, making it an ideal choice for a variety of industrial and commercial applications.
| Rated primary current (A) | Accuacy classes combination | Rated secondary output(VA) | 1s thermal current(kA) | Rated dynamic current(kA) | ||
| 0.2S | 0.2(0.5) | 10P | ||||
| 5 | 0.2S/10P10 0.2S/10P15 0.2/10P10 0.2/10P15 0.5/10P10 0.5/10P15 |
10 | 10 | 15*, 20 | 0.5 | 1.25 |
| 10 | 1 | 2.5 | ||||
| 15 | 1.5 | 3.75 | ||||
| 20 | 3 | 7.5 | ||||
| 25 | 3.75 | 9.3 | ||||
| 30 | 4.5 | 11.2 | ||||
| 40 | 6 | 15 | ||||
| 50 | 7.5 | 18.7 | ||||
| 75 | 10 | 25 | ||||
| 100 | 15 | 37.5 | ||||
| 150 | 22.5 | 56 | ||||
| 200 | 31.5 | 80 | ||||
| 300 | 10*, 15 | 45 | 112.5 | |||
| 400 | 45 | 112.5 | ||||
| 500 | 63 | 130 | ||||
| 600 | 80 | 140 | ||||
| 800 | 15*, 30 | 80 | 140 | |||
| 1000 | 80 | 140 | ||||
| 1200 | 100 | 160 | ||||
Note: In the table, the data marked with*are the parameters of general products.
