Circuit breakers play a prominent role in enhancing and balancing the continuous use of electrical equipment and components. The circuit breaker design can vary and so can their functions. However, air circuit breakers and vacuum circuit breakers are used on both a dominant and prominent scale. The questions often arise questioning the acb and vcb difference. This blog will aid in finding the difference between acb and vcb. It will also explore the advantages and disadvantages of using acb and vcb. It will also answer where vcb can be preferred more than acb. For the best electrical equipment, Liyond can provide quality products and services.
What is vcb? A vacuum circuit breaker is a circuit breaker that can provide the functionality of arc quenching where the vacuum is situated. They are considered beneficial for medium voltage applications.
Vacuum circuit breaker technology is good for medium voltage vacuum circuit breaker. The opening and closing of current associates itself to the arc interruption and the contacts happening in a vacuum chamber. There is a steel arch chamber present in the middle of this component. They are symmetrically designed and arranged in insulators made of ceramic.
When it comes to the current that carries contacts, the material utilized in it can play a crucial role in the performance of the VCB. VCB is dominantly relied upon when it comes to using them as an interruption technology. They are used as medium voltage switchgear. They are also relied upon because they require less maintenance compared to most of the other circuit breakers.
Along with other various types of vacuum circuit breakers, there is an indoor vacuum circuit breaker as well. The Cr/Cr material is the best material to be used in the construction of vacuum circuit breaker contacts. The contacts play a crucial role in the performance of VCB. Additionally, The vacuum circuit can transform into a cut shape and spiral shape. There would also be a field contact of the magnetic axial.
Air circuit breakers are one of the most important types of circuit breakers. Air circuit breakers are also known as ACB. ACB is circuit operation breakers that run in the air for an arc extinguishing medium. They are used in electrical circuits that carry a charge of 800 to 10K amps. They are used to provide short circuit protection and overcurrent protection.
Various switchgear and ACB can be seen in the market for their respective purposes. They are generally qualitative in performance, durable, easy to install, and are hassle-free with their maintenance.
Air circuit breakers carry a complex internal structure to them. They are dominantly used for LV interruption. They can have two pairs of contacts. The first is the arcing contact that is constructed from carbon, and the second is the main pair of contacts that are constructed from copper material. However, the arcing contacts are separated. They are taken upwards by the electromagnetic force and the thermal action. Air circuit breakers are dominantly used in industrial plants and electrical machines because they can provide reliable protection to them.
In a vacuum circuit breaker, the arc is created when the ionization of the metal oils takes place. The contacts are divided when abnormal conditions take place, or when the arc gets stuck in the contacts. The material of the contacts also plays a vital role when it comes to their performance.
When it comes to the vacuum breakers, the arc interruption that takes place inside them would be different from the other types of circuit breakers. When the division of the contact takes place, it will release a vapor. This will be made of positive ions that are removed from the material of the contact. Moreover, they will be filled in the contact shape.
If the current is decreased, the vapor will not stay. The density of the vapor will be dependable on the current present in the arc. When the current arrives at level zero, the vapor density is lowered, and the dielectric strength is recovered by the medium.
Also, if the interfered current is small, then the arc will have many parallel paths. The overall current will be divided into various parallel arcs. Furthermore, the repelling of each other will take place, and they would be spread in the contact surface. Fast vaporization can take place on the contact surface where a high value of current is present.
During this case, the arc gets dominant in the minor regions. Probably, the arc remains in a scattered state when the interruption of the arc takes place. The arc will hit again when there is a quick elimination from the contact surface.
ACB works with the contacts in the free air. The main contacts open primarily when the circuit breaker is opened. During this time the arc is in contact with each other. When the arc contacts are divided, the process of arcing starts to take place. The arc is placed amongst them when their arcing contacts are divided.
The arc is taken upwards by electromagnetic forces and thermal action. The travel of the arc ends through the arc runner. When the arc goes upwards, it is divided by the arc splitter plates. Further, the arc is extinguished by the method of lengthening, cooling, and splitting.
Air circuit breakers work well for industrial plants and auxiliaries for the power stations. This is because they can provide defensive barriers to electrical machines like transformers, generators, and more. Moreover, they can provide the same defense barrier to industrial plants as well. They can raise the resistance of the arc by using splitting, cooling, and lengthening as techniques to provide high resistance power. Air circuit breakers air break principle is used in AC circuits and DC circuits for charges of up to 12kV.
The arc chute principle carries inefficiency in low current. The electromagnetic fields are weak as well. The arc movement in the chute can make it slower. High speed of interruption is not actually obtained. When the air blast takes place when meeting the interruption in the arc, a loud level of noise is produced.
Moreover, the air is discharged into the atmosphere, which is not good for environmental concerns. The re-striking voltage is also a problem faced by many. The air compressor plants have to be maintained. There is a current chopping problem.
The vacuum circuit breakers can be reliable in cases of providing high insulating strength. Therefore, they carry better arc quenching features than other methods. Vacuum circuit breakers have a longer life, therefore, they can make a good investment, and can be reliable as well.
In terms of maintenance, they are simple to maintain and are hassle-free. They can also ensure noiseless operation. There is no concern for fire hazards present. Vacuum circuit breaker do not release exhaust gas into the atmosphere. Thus, they are environmentally friendly as well. Incidents such as explosions can be prevented. This will provide more safety to the personnel working in their operative areas.
Vacuum circuit breakers are not budget-friendly. They can exceed the voltage of 38 k Volts. When vacuum circuit breakers are designed in lesser quantities, they are not reasonable in terms of cost-effectivity. Furthermore, in the case of extra high voltage, the price of the breaker takes a hike. This happens because 2 numbers of circuit breakers are required to be attached in a series for the higher voltages. But as a premium vcb manufacturer, this would not be the problem for Liyond, because we manufacture high performance vacuum circuit breakers by our own factory, they are in good quality and at a favorable price.
Vacuum circuit breakers can be beneficial for high voltage currents. They can be used for proving interruptions in out-of-phase current and double earth faults. They can be used in substations and generators. This circuit breaker can also be used in railway applications as it can provide traction current and electric supply switching. They can also provide switches to motor drives. They are also used in porcelain housed circuit breakers. These circuit breakers are used in metal-clad switchgear.
Air circuit breakers can be used to provide control of power in industrial plants and station auxiliaries. They are dominantly used to provide protection to plants where there is an increased risk of the possibility of fire or explosions.
The air circuit breaker carries an air brake principle that is used in ac and dc circuits for up to 12KV. This breaker is used in an electricity sharing system. They also carry high resistance power that helps in increasing the resistance of the arc by the method of lengthening, cooling, and splitting.
Air circuit breakers and vacuum circuit breakers are both important circuit breakers with regard to the functions they can provide. The difference between air circuit breakers and vacuum circuit breakers are many.
Vacuum circuit breakers are best for hv circuit breaker. Air circuit breakers can be best for medium voltage use. Air circuit breakers are dependable on the arc extinguishing device to stretch the arc. The air is being dependent upon to provide a cooling mechanism to the arc. On the other hand, a vacuum circuit breaker is dependent on the vacuum for the method of arc extinguishing. A vacuum bubble is present inside.
In the air circuit breaker, there must be a decent amount of compressed air present in the air storage before the breaker starts working. The opening and closing action in the air circuit breaker makes it dependent on the compressed air present. A minor amount of air is released to the extinguishing chamber through the means of a ventilation plug. Additionally, the extinguishing chamber also uses a supporting bottle and main valve in this process. The pressure intervenes from any external humid air from entering. Another difference between air circuit breaker and vacuum circuit breaker is that the internal structure of VCB is more simple than the one present in the ACB. Because the structure of ACB is more complex, it also gives it more life, and the rate of failure is lesser.
The vacuum circuit breaker is dependent on the vacuum to function. It cannot use air as a mechanism because of the presence of a vacuum. Therefore, it does not require a specific air storage medium. The vacuum circuit breaker is dependent on the electromagnet and electro valve to control the circuit.
Air circuit breakers are also more expensive than vacuum circuit breakers because they have a more complex structure. Circuit breaker service can be question arisen as well.
Air circuit breakers and vacuum circuit breakers are both important circuit breakers with regard to the functions they can provide. The difference between air circuit breakers and vacuum circuit breakers are many.
Vacuum circuit breakers are best for hv circuit breaker. Air circuit breakers can be best for medium voltage use. Air circuit breakers are dependable on the arc extinguishing device to stretch the arc. The air is being dependent upon to provide a cooling mechanism to the arc. On the other hand, a vacuum circuit breaker is dependent on the vacuum for the method of arc extinguishing. A vacuum bubble is present inside.
In the air circuit breaker, there must be a decent amount of compressed air present in the air storage before the breaker starts working. The opening and closing action in the air circuit breaker makes it dependent on the compressed air present. A minor amount of air is released to the extinguishing chamber through the means of a ventilation plug. Additionally, the extinguishing chamber also uses a supporting bottle and main valve in this process. The pressure intervenes from any external humid air from entering. Another difference between air circuit breaker and vacuum circuit breaker is that the internal structure of VCB is more simple than the one present in the ACB. Because the structure of ACB is more complex, it also gives it more life, and the rate of failure is lesser.
The vacuum circuit breaker is dependent on the vacuum to function. It cannot use air as a mechanism because of the presence of a vacuum. Therefore, it does not require a specific air storage medium. The vacuum circuit breaker is dependent on the electromagnet and electro valve to control the circuit.
Air circuit breakers are also more expensive than vacuum circuit breakers because they have a more complex structure. Circuit breaker service can be question arisen as well.
This blog has explored the difference between air circuit breakers and vacuum circuit breakers. They both carry their own set of functions to perform. ACB and VCB have certain advantages and disadvantages which have been explained above.
VCB can be ideal for usage in high voltage and medium voltage conditions. Their operating mechanism, and structure, also act as a difference between acb and vcb. Their application/function has also been discussed. For more information on ACB and VCB, Liyond can be contacted.
